Mazda Astina 1998 Dashboard Fuse Box/Block Circuit Breaker Diagram

Mazda Astina 1998 Dashboard Fuse Box/Block Circuit Breaker Diagram



SymbolFuse MapAmps
1Spare10A
2Door Lock30A
3Spare15A
4Cigar15A
5Spare30A
6Radio10A
7Engine10A
8Illumi10A
9Opener15A
10Turn10A
11Blower15A
12P/Window30A
13R.DEF15A
14A/C10A
15Wiper20A
16Sun Roof15A
17Meter15A
18Stop20A
19Hazard15A
20Room15A

Mazda Astina 1998 Dashboard Fuse Panel/Board – Fuse Symbol Map
