Mazda Demio 2008 Fuse Box/Block Circuit Breaker Diagram

Mazda Demio 2008 Fuse Box/Block Circuit Breaker Diagram



FuseAmps.Description
HORN15AHorn
H/L LH15AHeadlamps (High/Low Left, High Beams)
H/L RH15AHeadlamps (High/Low Righ, High Beams)
EEC5AEEC (KPWR)
HEGO15AHego 1,2, CMS1,2, VMV
FUEL20AFuel Pump , EEC (FPM)
DIODE-
DIODE-
H/L RELAY MICRO-Headlamp (High/Low, Right/Left Relay)
INJ30AEEC (VPWR), EVR, MAF, IAC, Bulkhead
MAIN120AMain
ALT15AAlternator/Regulator
(DRL)15ADaytime Running Lamps (DRL) Unit (feed), DRL Relay
(DRLZ)(HELV)15A (DRLZ)DRL Module, HLEV
10A (HLEV)
PWR 115AAuxiliary Power Point
FOG20AFoglamps, Foglamp Indicator
A/C15AA/C Clutch
(ABS)25AAnti Lock Brake System (ABS) SOL
PWR 215AAuxiliary Power Point
IG MAIN40AStarter
HTR40ABlower Motor, Blower Motor Relay
BTN 140AJB Accessory Relay, Radio, Cigar Lighter, Cluster, Power Mirror, GEM, Electronic Flasher Control
(ABS)60AABS Motor
BTN 240AJB Radio, Cluster, Dome Lamps, Map Lamps, Cruise Control, Power Seat, Horn
MAIN FAN40A (2.0L)Main Fan
50A (3.0L)
R DEF30ARear Defroster
ADD FAN40A (2.0L)Add Fan
50A (3.0L)
EEC MAIN ISOEEC Relay
FUEL PUMP ISOFuel Pump Relay
MAIN FAN ISOLow Speed Fan Control Relay (2.0L Engine) High Speed Fan Control Relay 1 (3.0L Engine)
ADD FAN ISOHigh Speed fan Control Relay 1 (2.0L Engine) Low Speed Fan Control Relay (3.0L Engine)
DEF RELAY ISORear Defroster Relay
ST RELAY ISOStarter Relay
ADD FAN 2 ISOHigh Speed Fan Control Relay 2 (3.0L Engine) Medium Speed Fan Control Relay (2.0L Engine)
FOG RELAY MICROFoglamp Relay
A/C RELAY MICROA/C Clutch Relay

Mazda Demio 2008 Fuse Panel/Board – Fuse Symbol Map
