VW Karman Ghia 1972 Fuse Box/Block Circuit Breaker Diagram
| FUSES | USAGE |
|---|---|
| 1 | Left Headlamp, Low Beam |
| 2 | Right Headlamp, Low Beam |
| 3 | Left Headlamp, Main Beam |
| 4 | Right Headlamp, Main Beam |
| 5 | Left Rear Light |
| 6 | Right Rear Light |
| 7 | Brake Lights, Direction Indicators, Windscreen Wipers |
| 8 | Horn, Interior Lights |
VW Karman Ghia 1972 Fuse Panel/Board – Fuse Symbol Map
