Alfa Romeo Spider 1995 Fuse Box/Block Circuit Breaker Diagram

Alfa Romeo Spider 1995 Fuse Box/Block Circuit Breaker Diagram



FUSEAMPCIRCUITS PROTECTED
125APower Windows-Two-Point Motorized Safety Belts (Pasive Restraints)
220ARear Fog Lamp Device - Map Reading Lamp
320AHeated Rear Window
47.5ADigital Clock, Power Mirrors Courtesy Lights, Stop Lights
57.5ARadio (if Fitted), Direction Indicator and Hazard Light Relay
610AWindshield Wiper Motor, Washer Pump
710ABack-Up Lights, Cigar Lighter, Speedometer, Ventilation Electric Fan
87.5APower Window Relay, Heated Rear Window Relay, Instrument Warning Lights
97.5AR.H Front Parking Light, L.H Rear Parking and Stop Lights, Engine Compartment Lights
107.5AL.H Front Parking Light, R.H Rear Parking and Stop Lights, Baggage Compartment Light
117.5AL.H low Beam Headlamp
127.5AR.H Low Beam Headlamp
137.5AL.H High Beam Headlamp

Alfa Romeo Spider 1995 Fuse Panel/Board – Fuse Symbol Map
