BMW E28 V6 1989 Fuse Box/Block Circuit Breaker Diagram
| SYMBOL | DESCRIPTION |
|---|---|
| C54 | K37 High Beam Relay |
| C51 | K163 PCM Power Relay |
| C69 | K33 Horn Relay |
| C50 | K4 Fuel Pump Relay |
| C53 | K36 Low Beam Relay |
| C61 | V8 Starter Relay Diode |
| C52 | K22 Starter Relay |
| C465 | K32 A/C Wide Open Throttle (WOT) Relay |
| C2000 | K107 A/C Clutch Relay |
| C432 | K45 Engine Cooling Fan Relay |
| C431 | K5 Daytime Running Lamps (DRL) Relay |
| C430 | K46 High Speed Engine Cooling Fan Relay |
BMW E28 V6 1989 Fuse Panel/Board – Fuse Symbol Map
