Chevy Optra LT 2004 Front Fuse Box/Block Circuit Breaker Diagram

Chevy Optra LT 2004 Front Fuse Box/Block Circuit Breaker Diagram



FUSE NO.AMPSCIRCUIT
130ARadiator Fan
210AStop Lights
315ACigarette Lighter, Radio, Clock, Interior Lights, Central Locking System
415AEmergency Flasher System
515AElectric Fuel Pump
6-Vacant
710ATail, Parking and Side Marker Lights Left
810ATail, Parking and Side Marker Lights Right
910AHigh Beam Right, High Beam Indicator Light
1010AHigh Beam Left
1115AWindshield Wiper/Washer
1215ARear Window Wiper/Washer, Coolant Level Checking Device, Outside Rear View Mirror Adjustment
1315ARear Window Defogger, Heated Rear View Mirror
1420AFresh Air Fan, Air Conditioner (Factory Installed)
1510ABack-up Lights, Shift Console light (Auto, Trans)
1615AHorn
17-Vacant
1810AThrottle Switch
1910ATurn Signal
2010ALicense Plate Lights, Glove Compart Light
2110ALow Beam Left
2210ALow Beam Right

Chevy Optra LT 2004 Front Fuse Panel/Board – Fuse Symbol Map
