Chrysler T&C 1998 Limited Fuse Box/Block Circuit Breaker Diagram
| Fuse Symbol | Amps | Circuits Protected |
|---|---|---|
| Maxi Fuse | ||
| 1 | 50A | Ignition Switch |
| 2 | 40A | Ignition Switch |
| 3 | 50A | Cooling Fan (High Speed) |
| 4 | 30A | PCM Power Relay |
| 5 | 40A | Fuse Junction Panel Fuses 10,19,21,23,25,27 |
| 6 | 30A | Starting System |
| 7 | 50A | Fuse Junction Panel, Fuses 1,3,5,7,9,31 |
| 9 | 50A | Anti-Lock Brakes |
| 10 | 40A | Rear Defrost |
| 11 | 40A | Accessory Delay Relay(Signature/Carier), Power window Relay (Executive), Fuse Junction Panel, Fuse 29 |
| 12 | 30A | Air Suspension |
| 25 | 30A | Power Lumbar, Passenger Power Seat |
| 26 | 30A | Cooling Fan (Low Speed) |
| 27 | - | Not Used |
| Mini Fuse | ||
| 13 | 15A | Charging System |
| 14 | 20A | Fuel Pump |
| 15 | - | Not Used |
| 16 | 30A | Heated Seats |
| 17 | 10A | Air Suspension |
| 18 | 15A | Horn |
| 19 | 30A | Subwoofer, Fuse Junction Panel, Fuse 30 |
| 20 | 15A | Fuel Injectors, PCM |
| 21 | 15A | Heated Oxygen Sensor, Solenoids EVAP Canster Vent Solenoid Valve, EGR Vacuum Regulator, EVAP Canster Purge Solenoid |
| 22 | - | Not Used |
| 23 | - | Not Used |
| 24 | 20A | Auxiliary Power Outlet |
Chrysler T&C 1998 Limited Fuse Panel/Board – Fuse Symbol Map
