Datsun 300 ZX 1998 Under The hood Fuse Box/Block Circuit Breaker Diagram
| Fuse Symbol | Amps | Fuse Map |
|---|---|---|
| 1 | 10A | ECCS, Bulb Check Relay |
| 2 | 10A | Radiator Fan Relay, Radiator Fan Motor, Air Conditioner System, Daytime Light Control Unit, Theft Warning Relay |
| 3 | 20A | Stoplight Switch, Cruise Control Unit, A/T Control Unit, Shift Lock Control Unit, Anti-Lock Brake System Control Unit, Power Steering Control Unit, Radiator Fan Motor, HICAS Control Unit |
| 4 | 10A | Shift Lock Control Unit, Key Switch |
| 5 | 15A | Front Foglights, Headlight Washer Motor |
| 6 | 20A | Anti-Lock Brake System |
| 7 | 10A | Horn, Time Control Unit, Cruise Control |
| 8 | 15A | Right Headlight, Daytime Light Control Unit |
| 9 | 15A | Left Headlight, Daytime Light Control Unit |
| 10 | 10A | (1992-95) A/T Control Unit, Theft Warning Control Unit, Auto A/C Control Amp, Key Hole Illumination, Footlights, Audio, HICAS Control Unit, Clock, Air Bag Control Unit |
Datsun 300 ZX 1998 Under The hood Fuse Panel/Board – Fuse Symbol Map
