Ford Escort 1997 Under Hood Electrical Circuit Wiring Diagram
| SYMBOL | DESCRIPTION |
|---|---|
| 1 | Headlamp Relay |
| 2 | Speed Control Amplifier |
| 3 | Blower Motor Resistors |
| 4 | Blower Motor |
| 5 | Powertrain Control Module (PCM) |
| 6 | Fuel Pump Relay (1.8L) |
| 7 | PCM Power Relay (1.9L) |
| 8 | Fuel Pump Relay (1.9L) |
| 9 | Octane Adjust Plug (1.9L) |
| 10 | Instrument Panel Dimming Module |
| 11 | Electronic Flasher |
| 12 | Door Lock/Unlock Relay |
| 13 | Blower Motor Relay |
Ford Escort 1997 Under Hood Electrical Circuit Symbol Map
