Ford F250 1992 Electrical Circuit Wiring Diagram
| SYMBOL | DESCRIPTION |
|---|---|
| PIN 1 | Check For Ground |
| PIN 2 | This is The Flash Source For The Coil |
| PIN 3 | Check This For Power With Key On And Also Cranking |
| PIN 4 | Should Show RPM When Engine Cranking (RPM Meter Needed) |
| PIN 5 | Spout Command From PCM (Computer) |
| PIN 6 | Input From Stator When Distributor Turning |
Ford F250 1992 Electrical Circuit Symbol Map
