Ford Falcon UTE 1999 Engine Fuse Box/Block Circuit Breaker Diagram

Ford Falcon UTE 1999 Engine Fuse Box/Block Circuit Breaker Diagram



Fuse SymbolRatingFuse Map
E50APower Seats, LH Power Lumbar
F60ABlower Motor, Cigar
G60AIgnition Switch
H30AFuel Pump Relay/ Fuel Pump
J40ATrailer Battery Charger Relay, Trailer Adapter Battery Feed
K30ATrailer Back-Up Lamp Relay, Trailer Running Lamp Relay
L-Plug-in Diode
M10ATrailer RH Turn/Stop Lamp
N10ATrailer LH Turn/Stop Lamp
P10AClassI Trailer Running Lamps, ClassII Trailer Running Lamp Relay
R15ADRL Module, Horn Relay, Hood Lamp
S60AHeadlamp Switch, I/P
T60ATrailer Tow, AUX, Battery

Ford Falcon UTE 1999 Engine Fuse Panel/Board – Fuse Symbol Map
