Oldsmobile Alero V6 2003 Fuel Pump Electrical Circuit Wiring Diagram
| Symbol | Description |
|---|---|
| 1 | Cap-Fuel Pressure Connection |
| 2 | Valve Assembli-Fuel Pressure Connection |
| 3 | Rail Assembly-RH Fuel |
| 4 | Bracket-Retainer and Spacer |
| 5 | Screen-Filter |
| 6 | O-Ring-Pressure Regulator Inlet |
| 7 | Regulator Assembly-Fuel Pressure |
| 8 | Screw-Pressure Regulator Attaching |
| 9 | O-Ring-Upper Injector (Black) |
| 10 | Clip-Injector Retainer |
| 11 | Injector Assembly-Fuel |
| 12 | Back-O-Ring |
| 13 | O-Ring-Lower Injector (Brown) |
| 14 | Screw-Rail Mounting Bracket Attaching |
| 15 | Bracket-Rail Mounting(2 EA) |
| 16 | Rail Assembly-LH Fuel (With Crossover Tube) |
| 17 | Clip-Crossover Tube Retainer |
| 18 | O-Ring-Crossover Tube |
Oldsmobile Alero V6 2003 Fuel Pump Electrical Circuit Symbol Map
