| F1 | 50A | Rear Window Demister Relay, Fuse Block - Instrument Panel |
| F1 | 15A | Hazard Lamps Switch |
| F2UA | 30A | Ignition Switch |
| F2UB | 15A | Engine Control Module, Ignition Coil 1, Ignition Coil 2, Ignition Coil 3, Ignition Coil 4, Ignition Coil Module, K103 LPG Control Module |
| F3UA | 40A | Ignition Switch |
| F3UB | 15A | Heated Oxygen Sensor, Exhaust Gas Recirculation Valve, Evaporative Emissions Purge Solenoid (EVAP) Valve, Heated Oxygen Sensor 1, Camshaft Position Sensor, Heated Oxygen Sensor 2 |
| F4UA | 50A | Electronic Brake Control Module (EBCM) |
| F4UB | 10A | Engine Control Module, Transmission Control Module (MFL) |
| F5UA | 20A | Seat Heating Relay |
| F5UB | - | Not Used |
| F6UA | 30A | Cooling Fan High Speed Relay |
| F6UB | 15A | Engine Control Module, Ignition Coil 1, Ignition Coil 2, Ignition Coil 3, Ignition Coil 4, Ignition Coil Module, LPG Control Module |
| F7UA | 40A | Electronic Brake Control Module (EBCM) |
| F7UB | 10A | A/C Compressor Clutch |
| F8UA | - | Not Used |
| F8UB | 20A | Cooling Fan Resistor |
| F9UA | 30A | Starter Relay |
| F9UB | 15A | Fuel Pump Relay |
| F10UB | 10A | Number Plate Lamp, Tail Lamp - Left, Park/Indicator Lamp - Left, Headlamp Levelling Actuator - Left |
| F11UB | 10A | Park/Indicator Lamp - Right, Headlamp Levelling Actuator - Right, Tail Lamp - Right, Interior Lamp Relay |
| F12UB | 20A | Headlamp Assembly - Right, Headlamp Assembly - Left, Instrument Cluster |
| F13UB | 10A | Headlamp Assembly - Left, Headlamp Levelling Switch |
| F14UB | 10A | Headlamp Assembly - Right |
| F15UB | 10A | Horn Relay, Bonnet Ajar Switch |
| F16UB | 10A | Front Fog Lamp Relay |
