Chevy Deluxe K-25 1983 Fuse Box/Block Circuit Breaker Diagram
| Symbol | Description |
|---|---|
| A | Choke |
| B | Fuse-Heater/Air Cond |
| C | Receptacle-Accessory |
| D | Receptacle-Ignition (Key on Power) |
| E | Fuse-Auxiliary Heater/ AC |
| F | Fuse-Instrument Cluster Feed (Gauges) |
| H | Fuse-Tai Light, Courtesy Lamps |
| I | Fuse-Wipers |
| J | Fuse-Horn |
| K | Receptacle-Power Accessories & Other Accessories |
| L | Receptacle-Batery (Constant Power) |
| N | Not Used P-Fuse-Turn Signals, Reversing Lamps |
| R | Fuse-Fuse-Radio & TCS (Idle) |
| X | Receptacle-LOS |
| Z | Fuse-Stop (Brake) Lights, Traffic Hazard Flashers |
Chevy Deluxe K-25 1983 Fuse Panel/Board – Fuse Symbol Map
