Subaru GC8 1997 Mini Fuse Box/Block Circuit Breaker Diagram
| Symbol | Amps | Description |
|---|---|---|
| No.1 | 15A | Back-Up Light, Turn Signal Light |
| No.2 | 20A | Windshield Wiper and Washer |
| No.3 | 15A | Accessory Socket, Remote Control Rear View Mirrors |
| No.4 | 15A | Seat Heater |
| No.5 | 10A | Tail Light (Right Side) |
| No.6 | 15A | Front Fog Light |
| No.7 | 20A | Rear Window Defogger |
| No.8 | 15A | SRS AIRBAG |
| No.9 | 10A | Illumination Brightness Control |
| No.10 | - | Empty |
Subaru GC8 1997 Mini Fuse Panel/Board – Fuse Symbol Map
